IOL-Master

Ambient Temperature During Operation	0.0 ... 45.0°C
Communication	IO-Link specification V 1.1;IO-Link port class A
Connection	USB Mini USB B;TYPE 2.0
Connection 2	Socket M12
Connection 3	Power supply
Functions	With PC
Inverse Polarity Protection	Yes
Power Supply	5 V / 500 mA (PC USB);24 V / 80 mA (IO-Link device from USB);24 V / 1 A (IO-Link device from the power supply)
Protection Class	III, operation on protective low voltage
Protection Type	IP 20
Scope Of Delivery	USB IO-Link Master V2;USB A-B cable;Power supply 24 V DC / 24 W
To Be Used For	For devices with IODD Specification 1.0.1 and 1.1
