KLT-M6-T2-0.5-L20

Bending Radius	15.0 > mm
Characteristics	With cable protection bushing;Integrated optics
Design	Thread
Fiber	Parallel 0.5 mm 2.0
Length	2000.0 mm Can be shortened
Light Aperture	axial
Light Spot Size	Ø 1.0 mm (at distance of 20 mm)
Material	Stainless steel;PE Sensor probe;Coating
Operating Principle	Diffuse sensor
Range	20.0mm
Resolution	0.05 mm
Resolution1	at 20 mm distance
Temperature Resistance	-55.0 °C 70.0 °C
Thread	M6 x 0.75
To Be Used For	Device series OLV-K Amplifier
