VL-TZSA-TZKA-4JBK-60X-S
Part Number: VL-TZSA-TZKA-4JBK-60X-S
Article Number: 214745
Technical Details
| Characteristics | Metal nut |
|---|---|
| Connection | Connector M8 4-pin |
| Connection 2 | Socket M8 4-pin |
| Cross Section | 0.25 x 0.25 mm 4.0 |
| Design | Straight / straight |
| Diameter | 4.5 mm |
| Drag Chain Compatible | 1.0 |
| Drag Chain Properties | 10.0 max. Mio. |
| Length | 600.0 mm |
| Material | Die-cast zinc;Die-cast zinc Socket;Connector |
| Max Moving Speed | 3.0 m/s |
| Max Torsion | 180.0 ± °/m |
| Min Bending Radius | 10 x Ø |
| Protection Class | III, operation on protective low voltage |
| Protection Type | IP 65;IP 66K;IP 67 |
| Service Voltage | 50;60 |
| Thread | M8 x 1 |
| Tightening Torque (max.) | 0.4 Nm |
| Weight | 28.0 g |
